Pleasanton Municipal Airport

US Flag

ICAO: KPEZ

FAA: PEZ

Pleasanton Weather (°F)

KPEZ (0.1 NM at True Heading of 43)
METAR: KPEZ 020555Z AUTO 11003KT 10SM SCT018 24/21 A2991 RMK AO2 T02360213 10317 20235 403330215
TAF: N/A

Location

Latitude:
 28-57-15.1000N (28.954194)
Longitude:
 098-31-11.9000W (-98.519972)
Elevation:
 430.4 feet MSL (131 m MSL)
Magnetic Variation:
 3.7 E (as of June 2023 from WMM2020 model)
Time Zone:
 UTC -6.0 (Standard Time)
UTC -5.0 (Daylight Savings Time)
From City:
 03 N.M. W of Pleasanton, Texas
Found On:
 San Antonio Chart
FAA Region:
 ASW

Contacts

Manager:
Publicly owned:
JOHN ROBERTS
PO BOX 209
PLEASANTON, TX 78064
(830) 569-3155		 CITY OF PLEASANTON
BOX 209
PLEASANTON, TX 78064
830-569-3867

Operations

Airport Status:
 Operational
Facility Use:
 Public
Type:
 Airport
Activation Date:
 10/1970
Control tower:
 No
Attendance (Months/Days/Hours):
 Months/Days/Hours
Unattended
Boundary ARTCC:
 ZHU (Houston)
Responsible ARTCC:
 ZHU (Houston)
Lighting Schedule:
 SEE RMK
Segmented Circle Indicator:
 Yes
Traffic Pattern Altitude (MSL):
 1430 feet (436 m)
NOTAMs Facility:
 SJT
NOTAM-D Service:
 Yes
International Airport of Entry:
 No
Customs Landing Rights:
 No
Military Landing Rights:
 Yes
Civil/Military Joint Use:
 No

Based Aircraft

Single Engine:  19
Multi Engine:  2

Annual Operations (as of 10/13/2016)

Total Operations:  9280
Air Taxi:  200 2.2%
GA Local:  6000 64.7%
GA Itinerant:  2000 21.6%
Military Aircraft:  1080 11.6%

Communications

CTAF:  122.700
Unicom:  122.700
Approach:  SAN ANTONIO
118.05
118.05
118.05
118.05
118.05
Departure:  SAN ANTONIO
118.05
118.05
118.05
118.05
118.05
AWOS-3:  118.575 (830-569-5749)



    Fixed Based Operators (FBOs) & Fuel

    (Click on a business for detail)
    Please help us keep this information up to date. This is a FREE SERVICE just like everything else on Airport Guide! If you see that a business needs to be added, modified, or deleted please fill out our Update Form.

    Area Code: 830
    Business Name Frequency Phone Fuel Grade
    Page Aviation
           		569-5294 100LL
    To add, modify, or delete a business click here.

    Flight Service Stations

    Primary Alternate
    FSS on Field:  N
    FSS Name (ID):  San Angelo(SJT)
    Frequency:
    Toll Free Phone:  1-800-WX-BRIEF

    Instrument Procedures / Charts


    FAA Terminal Procedures valid from 0901Z 05/18/23 to 0901Z 06/15/23.

    There are various types of charts available for an airport. They are listed in the Page Type column. Here is a legend for those types:

    APD - Airport Diagram
    DP - Departure Procedure Charts
    HOT - Hot Spots
    IAP - Instrument Approach Procedure Charts
    MIN - Minimums
    STAR - Standard Terminal Arrival Charts
    Page Type Page Name Volume Action Since
    Last Cycle
    IAP RNAV (GPS) RWY 34 SC-3
    MIN ALTERNATE MINIMUMS SC-3
    MIN TAKEOFF MINIMUMS SC-3
    Terminal Procedures are only available for airports in several countries with more being added all the time. If you are looking for a specific country's charts, please send an email to support(at)airportguide.com stating the country name. This will be used to prioritize the implementation.

    Navigation Aids (Navaids) near KPEZ

    Navigational Aid (NAVAID) distances from the airport are listed in Nautical Miles (NM).

    Nearby Airports with Fuel

    Dist (NM) Name (Airport IDs) True Hdg Mag Hdg Fuel Grade
    23.1 Stinson Municipal Airport
    (SSF KSSF SSF)    		 6 2 100LL, Jet A
    29.0 Castroville Municipal Airport
    (KCVB CVB)    		 323 319 100LL, Jet A
    31.9 Mc Kinley Field Airport
    (T30)    		 255 251 100LL, Jet A
    34.9 San Antonio International Airport
    (SAT KSAT SAT)    		 4 0 100LL, Jet A
    35.2 Kenedy Regional Airport
    (2R9)    		 102 99 100LL, Jet A
    37.1 Twin-Oaks Airport
    (T94)    		 4 0 100LL
    41.4 Live Oak County Airport
    (8T6)    		 148 145 100LL, Jet A
    42.2 South Texas Regional At Hondo Airport
    (KHDO HDO)    		 305 301 100LL, Jet A
    47.0 Boerne Stage Field Airport
    (5C1)    		 348 344 100LL, Jet A
    47.3 Cotulla-La Salle County Airport
    (COT KCOT COT)    		 230 226 100LL, Jet A
    51.5 New Braunfels Ntl Airport
    (KBAZ BAZ)    		 28 25 100LL, Jet A, Jet A+
    64.1 Duval-Freer Airport
    (T19)    		 183 179 100LL
    66.0 San Marcos Regional Airport
    (KHYI HYI)    		 31 28 100LL, Jet A
    66.0 Garner Field Airport
    (UVA KUVA UVA)    		 283 279 100LL, Jet A
    68.1 Kerrville Municipal/Louis Schreiner Field Airport
    (ERV KERV ERV)    		 334 330 100LL, Jet A
    73.3 Dimmit County Airport
    (CZT KCZT CZT)    		 249 245 100LL, Jet A
    74.3 Rooke Field Airport
    (RFG KRFG RFG)    		 121 118 100LL, MOGAS
    75.3 Alfred C 'Bubba' Thomas Airport
    (T69)    		 136 133 100LL, Jet A
    77.3 Alice International Airport
    (ALI KALI ALI)    		 160 157 100LL, Jet A
    84.3 Victoria Regional Airport
    (VCT KVCT VCT)    		 93 90 100LL, Jet A

    Notices to Airmen (NOTAMS)

    NOTAMs

    List ALL KPEZ NOTAMs
    View KPEZ NOTAMs

    NOTAM Radius Search

    NOTAMS within

    Enter NOTAM radius search distance

    This field is required
    NM of KPEZ

    NOTAM Flight Path Search (Enter from two to five locations below)

    NOTAMS within

    Enter NOTAM radius search distance

    This field is required
    NM of KPEZ

    Remarks

    A110-1 FOR CD IF UNA TO CTC VIA FREQ, CTC SAN ANTONIO APCH AT 210-805-5516.
    A17 FOR SVCS CALL 830-569-3155.
    A42-34 MARKINGS FADED
    A57-16 APCH SLOPE 0:1 TO DSPLCD THR FM +6 FT FENCE AT DSPLCD THR 199 FT RIGHT ON RISING GROUND.
    A58-16 +4 FT FENCE FM THR TO 200 FT AT 200 FT R; +4 FT FENCE 98 FT FM THR ON CNTRLN; +15 FT ROAD 137 FT FM THR ON CNTRLN.
    A58-34 +3 FT FENCE FM THR TO 200 FT AT 200 FT LEFT AND 97 FT RIGHT.
    A70-FUEL-10 0LL FUEL SELF-SVC WITH MAJOR CREDIT CARD.
    A81-APT DUSK-DAWN. MIRL RWY 16/34 PRESET LOW INTST; TO INCR INTST ACTVT - CTAF.

    Runways

    Runway Summary

    Runways: 16/34
    Longest Runway: 16/34 is 4000 ft (1219 m) long
    Runways with an Instrument Approach:

    KPEZ Airport Runway Details

    Runway 16/34  4000 ft x 75 ft (1219 m x 23 m)
    Runway Length Source:  3RD PARTY SURVEY as of 10/06/2011
    Runway Edge Lights:  Medium Intensity

    Runway Weight Bearing Capacity (in thousands of pounds)
    Single Wheel Landing Gear:  4.0

    Runway 16

    Runway 34
    Elevation:
    		 430.3 400.2
    Latitude:
    		 28-57-34.0390N 28-56-56.1477N
    Longitude:
    		 098-31-18.4862W 098-31-05.3993W
    Runway True Alignment:
    		 163 343
    Glide Path Angle:
    		 4.0 degrees 3.0 degrees
    Traffic Pattern:
    		 Left Left
    Runway Markings Type:
    		 Nonprecision Instrument Nonprecision Instrument
    Runway Markings Condition:
    		Fair Poor
    Object at End:
    		 ROAD FENCE
    Object Height:
    		 15 4
    Distance from End:
    		 200 200
    Object Centerline Offset:
    		 135 ft. right of centerline 97 ft. right of centerline
    Visual Glide Slope Indicators:
    		 2-Light PAPI On Left Side Of Runway 2-Light PAPI On Left Side Of Runway
    Threshold Crossing Height:
    		 25 35
    Threshold Elevation:
    		 428.3
    Displaced Threshold:
    		 405
    Threshold Latitude:
    		 28-57-30.2052N

    Threshold Longitude:

    		 098-31-17.1627W

    Services

    Airframe Repair:
    		 Minor
    Powerplant Repair:
    		 Minor
    Fuel Available:
    		 100LL, Jet A
    Landing Fees:
    		 No
    Parking:
    		 Hangars and tiedowns available

    Maps & Diagrams

    KPEZ Sectional

    Flight Planning
    at skyvector.com

    KPEZ Diagram


    Do you have a better diagram of this ?
    Please share it with us.
