Stinson Municipal Airport

US Flag

San Antonio Weather (°F)

KSSF (0.1 NM at True Heading of 337)
METAR: KSSF 060053Z 16003KT 10SM CLR 13/10 A3016 RMK AO2 SLP213 T01280100
TAF: KSSF 052320Z 0600/0624 VRB02KT P6SM SKC FM061600 10004KT P6SM SKC

Location

Latitude:
29-20-13.1330N (29.336981)
Longitude:
098-28-15.7600W (-98.471044)
Elevation:
577.6 feet MSL (176 m MSL)
Magnetic Variation:
3.9 E (as of November 2021 from WMM2020 model)
Time Zone:
UTC -6.0 (Standard Time)
UTC -5.0 (Daylight Savings Time)
From City:
06 N.M. S of San Antonio, Texas
Found On:
San Antonio Chart
FAA Region:
ASW

Contacts

Manager:
Publicly owned:
MORRIS MARTIN
8535 MISSION RD
SAN ANTONIO, TX 78214
210-207-1800
CITY OF SAN ANTONIO
8535 MISSION RD
SAN ANTONIO, TX 78214
210-207-1800

Operations

Airport Status:
Operational
Facility Use:
Public
Type:
Airport
Activation Date:
06/1938
Control tower:
Yes
Attendance (Months/Days/Hours):
Months/Days/Hours
ALL/ALL/0700-2200
Boundary ARTCC:
ZHU (Houston)
Responsible ARTCC:
ZHU (Houston)
Lighting Schedule:
SEE RMK
Segmented Circle Indicator:
No
Beacon Color:
White-Green (Lighted Land Airport)
Traffic Pattern Altitude:
1578 feet (481 m)
NOTAMs Facility:
SSF
NOTAM-D Service:
Yes
International Airport of Entry:
No
Customs Landing Rights:
No
Military Landing Rights:
Yes
Civil/Military Joint Use:
No

Based Aircraft

Single Engine:  65
Multi Engine:  4
GA Helicopters:  5

Annual Operations (as of 05/10/2017)

Total Operations:  93157
Air Taxi:  3278 3.5%
GA Local:  59455 63.8%
GA Itinerant:  26046 28.0%
Military Aircraft:  4378 4.7%

Communications

CTAF:  118.200
Unicom:  122.950
Tower:  STINSON
118.2
379.9
Hrs: 0700-2200
Clearance Del.:  121.7 ;WHEN SSF TWR CLSD.
121.7 ;WHEN SSF TWR CLSD.
121.7 ;WHEN SSF TWR CLSD.
Ground:  121.7
379.9
Approach:  SAN ANTONIO
Departure:  SAN ANTONIO
ATIS:  128.8
Hrs: 24
ASOS:  (210-927-9391)
EMERG:  121.5
EMERG:  243.0



    Fixed Based Operators (FBOs) & Fuel

    (Click on a business for detail)
    Please help us keep this information up to date. This is a FREE SERVICE just like everything else on Airport Guide! If you see that a business needs to be added, modified, or deleted please fill out our Update Form.

    Area Code: 210

    Business Name Frequency Phone Fuel Grade
    San Antonio Aviation

    922-1203, -1228 100LL
    T & M Aviation

    Unicom 122.95 924-6634 100LL, Jet A
    To add, modify, or delete a business click here.

    Flight Service Stations

    Primary Alternate
    FSS on Field:  N
    FSS Name (ID):  San Angelo(SJT)
    Frequency:
    Toll Free Phone:  1-800-WX-BRIEF

    Instrument Procedures / Charts


    FAA Terminal Procedures valid from 0901Z 11/04/21 to 0901Z 12/02/21.

    There are various types of charts available for an airport. They are listed in the Page Type column. Here is a legend for those types:

    APD - Airport Diagram
    DP - Departure Procedure Charts
    HOT - Hot Spots
    IAP - Instrument Approach Procedure Charts
    MIN - Minimums
    STAR - Standard Terminal Arrival Charts
    Page Type Page Name Volume Action Since
    Last Cycle
    APD AIRPORT DIAGRAM SC-3
    DP ALAMO THREE SC-3
    DP ALAMO THREE[DELIMITER] CONT.1 SC-3
    DP ALISS FIVE (RNAV) SC-3
    DP ALISS FIVE (RNAV)[DELIMITER] CONT.1 SC-3
    DP BOWIE SEVEN SC-3
    DP BOWIE SEVEN[DELIMITER] CONT.1 SC-3
    DP LEJON FOUR SC-3
    DP MILET FOUR (RNAV) SC-3
    DP THREE RIVERS FOUR (RNAV) SC-3
    IAP RNAV (GPS) RWY 32 SC-3
    IAP VOR RWY 32 SC-3
    MIN TAKEOFF MINIMUMS SC-3
    STAR BRAUN THREE (RNAV) SC-3
    STAR BRAUN THREE (RNAV)[DELIMITER] CONT.1 SC-3
    STAR BRAUN THREE (RNAV)[DELIMITER] CONT.2 SC-3
    STAR CENTERPOINT TWO SC-3
    STAR LEMIG ONE SC-3
    STAR MARCS ONE SC-3
    STAR MARCS ONE[DELIMITER] CONT.1 SC-3
    STAR STONEWALL ONE SC-3
    Terminal Procedures are only available for airports in several countries with more being added all the time. If you are looking for a specific country's charts, please send an email to support(at)airportguide.com stating the country name. This will be used to prioritize the implementation.

    Navigation Aids (Navaids) near SSF

    Navigational Aid (NAVAID) distances from the airport are listed in Nautical Miles (NM).

    Nearby Airports with Fuel

    Dist (NM) Name (Airport IDs) True Hdg Mag Hdg Fuel Grade
    11.8 San Antonio International Airport
    (SAT KSAT SAT)
    0 356 100LL, Jet A
    14.0 Twin-Oaks Airport
    (T94)
    0 356 100LL
    19.9 Castroville Municipal Airport
    (KCVB CVB)
    271 267 100LL, Jet A
    23.1 Pleasanton Municipal Airport
    (KPEZ PEZ)
    186 182 100LL, Jet A
    25.9 Boerne Stage Field Airport
    (5C1)
    333 329 100LL, Jet A
    31.4 New Braunfels Regional Airport
    (KBAZ BAZ)
    45 41 100LL, Jet A, Jet A+
    37.0 South Texas Regional At Hondo Airport
    (KHDO HDO)
    272 268 100LL, Jet A
    44.2 Kenedy Regional Airport
    (2R9)
    133 129 100LL, Jet A
    45.5 Mc Kinley Field Airport
    (T30)
    227 223 100LL, Jet A
    46.0 San Marcos Regional Airport
    (KHYI HYI)
    43 39 100LL, Jet A
    50.0 Kerrville Municipal/Louis Schreiner Field Airport
    (ERV KERV ERV)
    320 316 100LL, Jet A
    61.3 Live Oak County Airport
    (8T6)
    162 158 100LL, Jet A
    65.8 Cotulla-La Salle County Airport
    (COT KCOT COT)
    216 212 100LL, Jet A
    66.2 Austin-Bergstrom International Airport
    (AUS KAUS AUS)
    38 35 100LL, Jet A
    67.0 Garner Field Airport
    (UVA KUVA UVA)
    263 259 100LL, Jet A
    79.6 Smithville Crawford Municipal Airport
    (84R)
    58 55 100LL
    85.0 Burnet Municipal Kate Craddock Field Airport
    (KBMQ BMQ)
    8 4 100LL, Jet A
    86.2 Dimmit County Airport
    (CZT KCZT CZT)
    235 230 100LL, Jet A
    86.4 Victoria Regional Airport
    (VCT KVCT VCT)
    109 106 100LL, Jet A
    86.7 Rooke Field Airport
    (RFG KRFG RFG)
    135 132 100LL, MOGAS

    Notices to Airmen (NOTAMS)

    NOTAMs

    List ALL KSSF NOTAMs

    NOTAM Radius Search

    NOTAMS within

    Enter NOTAM radius search distance

    This field is required
    NM of KSSF

    NOTAM Flight Path Search (Enter from two to five locations below)

    NOTAMS within

    Enter NOTAM radius search distance

    This field is required
    NM of KSSF

    Remarks

    A110-1 NUMEROUS ACFT OPERATING AT OR ABOVE 2500 FT MSL IN THE STINSON ARPT TFC AREA UNDER THE CTL OF SAN ANTONIO APCH.
    A110-2 PAEW ADJ ALL TWYS & RAMP AREAS MON-FRI 0700-1759.
    A110-4 FOR CD WHEN ATCT IS CLSD CTC SAT APCH AT 210-805-5516.
    A16 FAX: 210-207-1806
    A57-09 APCH SLOPE 36:1 TO DSPLCD THR TO 30 FT PLINE AT 1094 FT FM DSPLCD THR ACRS EXTENDED CNTRLN.
    A57-14 APCH SLOPE 26:1 TO DSPLCD THR, +32 FT TREE AT 863 FT FM DSPLCD THR ACRS EXTENDED CNTRLN.
    A57-32 APCH SLOPE 22:1 TO DSPLCD THR, +50 FT TREE AT 1140 FT FM DSPLCD THR ON CNTRLN.
    A58-09 +7 FT FENCE AT 25 FT; ROAD AT 75 FT ACROSS APCH.
    A58-14 +7 FT FENCE AT 21 FT, ROAD AT 52 FT ACROSS APCH; 24 FT TREE 195 FT FM THR AT 56 FT LEFT.
    A58-32 +5 FT FENCE 75 FT FM THR; ROAD AT THR 100 FT LEFT; +25 FT TREES 0 FT FM THR 200 FT LEFT, 19 FT TREES 153-200 FT FM THR ON CNTRLN.
    A81-APT DUSK-DAWN. MIRL RWY 09/27 & 14/32 PRESET MED INTST WHEN ATCT CLSD.

    Runways

    Runway Summary

    Runways: 09/27
    14/32
    Longest Runway: 09/27 is 5000 ft (1524 m) long
    Runways with an Instrument Approach:

    SSF Airport Runway Details

    Runway 09/27  5000 ft x 100 ft (1524 m x 30 m)
    Runway Length Source:  3RD PARTY SURVEY as of 04/09/2019
    Surface:  Asphalt - Good condition -
    Runway Pavement Class:
    Runway Edge Lights:  Medium Intensity

    Runway Weight Bearing Capacity (in thousands of pounds)
    Single Wheel Landing Gear:  30.0
    Dual Wheel Landing Gear:  75.0
    Dual Tandem Wheel Landing Gear:
    Dual Dual Tandem Wheel Landing Gear:

    Runway 09

    Runway 27

    Elevation:
    577.6 565.1
    Latitude:
    29-20-18.7690N 29-20-08.0300N
    Longitude:
    098-28-51.3780W 098-27-56.2295W
    True Magnetic Hdg.:
    103 283
    ILS Type:
    Glide Path Angle:
    3.0 degrees 3.0 degrees
    Traffic Pattern:
    Runway Markings Type:
    Nonprecision Instrument Nonprecision Instrument
    Runway Markings Condition:
    Good Good
    Arresting Device:
    Object at End:
    PLINE TREE
    Object Height:
    30 24
    Object Marked/Lighted?:
    Lighted
    Distance from End:
    644 959
    Object Centerline Offset:
    0 ft. left and right of centerline 203 ft. right of centerline
    Visual Glide Slope Indicators:
    4-Light PAPI On Left Side Of Runway 4-Light PAPI On Left Side Of Runway
    Runway Visual Range (RVR):
    Approach Light System:
    REIL:
    Yes Yes
    Touchdown Lights:
    Centerline Lights:
    Threshold Crossing Height:
    40 40
    Threshold Elevation:
    576.9
    Displaced Threshold:
    450
    Threshold Latitude:
    29-20-17.8034N

    Threshold Longitude:

    098-28-46.4180W
    Declared Distances
    Take Off Run Avbl. (TORA):
    Take Off Distance Avbl. (TODA):
    Actual Stop Dist. Avbl. (ASDA):
    Landing Dist. Avbl. (LDA):

    Runway 14/32  4128 ft x 100 ft (1258 m x 30 m)
    Runway Length Source:  3RD PARTY SURVEY as of 04/09/2019
    Surface:  Asphalt - Good condition -
    Runway Pavement Class:
    Runway Edge Lights:  Medium Intensity

    Runway Weight Bearing Capacity (in thousands of pounds)
    Single Wheel Landing Gear:  12.0
    Dual Wheel Landing Gear:  20.0
    Dual Tandem Wheel Landing Gear:
    Dual Dual Tandem Wheel Landing Gear:

    Runway 14

    Runway 32

    Elevation:
    572.0 552.9
    Latitude:
    29-20-29.6195N 29-19-55.9995N
    Longitude:
    098-28-19.2742W 098-27-52.7622W
    True Magnetic Hdg.:
    145 325
    ILS Type:
    Glide Path Angle:
    3.0 degrees 3.0 degrees
    Traffic Pattern:
    Runway Markings Type:
    Nonprecision Instrument Nonprecision Instrument
    Runway Markings Condition:
    Good Good
    Arresting Device:
    Object at End:
    TREES TREES
    Object Height:
    32 19
    Object Marked/Lighted?:
    Distance from End:
    279 200
    Object Centerline Offset:
    0 ft. left and right of centerline 203 ft. right of centerline
    Visual Glide Slope Indicators:
    2-Light PAPI On Right Side Of Runway 4-Light PAPI On Left Side Of Runway
    Runway Visual Range (RVR):
    Approach Light System:
    REIL:
    Yes Yes
    Touchdown Lights:
    Centerline Lights:
    Threshold Crossing Height:
    35 40
    Threshold Elevation:
    571.2 557.0
    Displaced Threshold:
    583 372
    Threshold Latitude:
    29-20-24.8685N 29-19-59.0318N

    Threshold Longitude:

    098-28-15.5272W 098-27-55.1529W
    Declared Distances
    Take Off Run Avbl. (TORA):
    Take Off Distance Avbl. (TODA):
    Actual Stop Dist. Avbl. (ASDA):
    Landing Dist. Avbl. (LDA):

    Services

    Airframe Repair:
    None
    Powerplant Repair:
    None
    Bottled Oxygen:
    None
    Bulk Oxygen:
    None
    Fuel Available:
    100LL, MOGAS
    Landing Fees:
    No
    Parking:
    Hangars and tiedowns available

    Maps & Diagrams

    SSF Airport Sectional

    Flight Planning
    at skyvector.com

    SSF Airport Diagram


    Do you have a better diagram of this Airport?
    Please share it with us.
