Flagler Exec Airport

US Flag
METAR: METAR KFIN 050255Z AUTO 00000KT 10SM SCT120 14/13 A3014 RMK AO2 T01400127

TAF: N/A

Reporting Station: KFIN (0.1 NM at True Heading of 16)
Visibility: 10+SM
Flight Category: VFR
Altimeter: 1020.7
Temperature: 14 C (57.2 F)
Dewpoint: 12.7 C (54.86 F)

Location

Latitude:
 29-27-54.5440N (29.465151)
Longitude:
 081-12-27.5340W (-81.207648)
Elevation:
 33.1 feet MSL (10 m MSL)
Magnetic Variation:
 7.1 W (as of December 2025 from WMM2020 model)
Time Zone:
 UTC -5.0 (Standard Time)
UTC -4.0 (Daylight Savings Time)
From City:
 06 N.M. S of Palm Coast, Florida
Found On:
 Jacksonville Chart
FAA Region:
 ASO

Contacts

Manager:
Publicly owned:
ROY SIEGER
201 AIRPORT ROAD
PALM COAST, FL 32164
386-313-4220		 FLAGLER COUNTY
1769 EAST MOODY BOULEVARD, #2, SUITE 302
BUNNELL, FL 32110
386-313-4125

Operations

Airport Status:
 Operational
Facility Use:
 Public
Type:
 Airport
Activation Date:
 08/1945
Control tower:
 Yes
Attendance (Months/Days/Hours):
 Months/Days/Hours
ALL/MON-SAT/0700-1800
Boundary ARTCC:
 ZJX (Jacksonville)
Responsible ARTCC:
 ZJX (Jacksonville)
Lighting Schedule:
 SEE RMK
Segmented Circle Indicator:
 Yes
Traffic Pattern Altitude (MSL):
 1033 feet (315 m)
NOTAMs Facility:
 FIN
NOTAM-D Service:
 Yes
International Airport of Entry:
 No
Customs Landing Rights:
 No
Military Landing Rights:
 No
Civil/Military Joint Use:
 No

Based Aircraft

Annual Operations (as of )

Communications

CTAF:  118.950
Unicom:  123.000
Tower:  FLAGLER TOWER
118.95
Hrs: 0600-2000
Clearance Del.:  121.75
Ground:  121.75
Approach:  DAYTONA
125.8
125.8
Departure:  DAYTONA
125.8
125.8
ATIS:  128.325
Hrs: 24
AWOS-3:  128.325 (386-437-7334)



    Fixed Based Operators (FBOs) & Fuel

    (Click on a business for detail)
    Please help us keep this information up to date. This is a FREE SERVICE just like everything else on Airport Guide! If you see that a business needs to be added, modified, or deleted please fill out our
    .

    Area Code: 904
    Business Name Frequency Phone Fuel Grade
    To add, modify, or delete a business
    .

    Flight Service Stations

    Primary Alternate
    FSS on Field:  N
    FSS Name (ID):  Gainesville(GNV)
    Frequency:
    Toll Free Phone:  1-800-WX-BRIEF

    Instrument Procedures / Charts


    FAA Terminal Procedures valid from 0901Z 11/27/25 to 0901Z 12/25/25.

    There are various types of charts available for an airport. They are listed in the Page Type column. Here is a legend for those types:

    APD - Airport Diagram
    DP - Departure Procedure Charts
    HOT - Hot Spots
    IAP - Instrument Approach Procedure Charts
    MIN - Minimums
    STAR - Standard Terminal Arrival Charts
    Page Type Page Name Volume Action Since
    Last Cycle
    APD AIRPORT DIAGRAM SE-3
    IAP RNAV (GPS) RWY 06 SE-3 Changed
    IAP RNAV (GPS) RWY 11 SE-3 Changed
    IAP RNAV (GPS) RWY 24 SE-3 Changed
    IAP RNAV (GPS) RWY 29 SE-3 Changed
    MIN ALTERNATE MINIMUMS SE-3 Changed
    MIN TAKEOFF MINIMUMS SE-3
    Terminal Procedures are only available for airports in several countries with more being added all the time. If you are looking for a specific country's charts, please send an email to support(at)airportguide.com stating the country name. This will be used to prioritize the implementation.

    Navigation Aids (Navaids) near KFIN

    Navigational Aid (NAVAID) distances from the airport are listed in Nautical Miles (NM).

    Nearby Airports with Fuel

    Dist (NM) Name (Airport IDs) True Hdg Mag Hdg Fuel Grade
    11.0 Ormond Beach Municipal Airport
    (KOMN OMN)    		 153 160 100LL, Jet A
    18.8 Daytona Beach International Airport
    (DAB KDAB DAB)    		 155 162 100LL, Jet A
    24.2 Deland Municipal-Sidney H Taylor Field Airport
    (KDED DED)    		 189 196 100LL, Jet A, UL94
    24.6 Spruce Creek Airport
    (7FL6)    		 159 166 100LL, Jet A+
    27.7 Palatka Municipal/Lt Kay Larkin Field Airport
    (28J)    		 294 301 100LL, Jet A
    28.1 New Smyrna Beach Municipal (Jack Bolt Field) Airport
    (KEVB EVB)    		 151 158 100LL, Jet A
    30.4 Northeast Florida Regional Airport
    (UST KSGJ SGJ)    		 346 353 100LL, Jet A
    32.7 Massey Ranch Airpark Airport
    (X50)    		 153 160 100LL, Jet A
    39.9 Umatilla Municipal Airport
    (X23)    		 215 222 100, 100LL
    41.3 Orlando Sanford International Airport
    (SFB KSFB SFB)    		 181 188 100LL, Jet A
    49.1 Bob White Field Airport
    (X61)    		 206 213 100LL
    49.4 Keystone Heights Airport
    (42J)    		 297 304 100LL, Jet A+
    49.6 Orlando Apopka Airport
    (X04)    		 203 210 100LL, Jet A
    49.8 Leesburg International Airport
    (LEE KLEE LEE)    		 219 226 100LL, Jet A
    54.2 Arthur Dunn Air Park Airport
    (X21)    		 158 165 100LL, Jet A
    54.7 Jacksonville Exec At Craig Airport
    (CRG KCRG CRG)    		 343 350 100LL, Jet A
    55.6 Orlando Exec Airport
    (ORL KORL ORL)    		 186 193 100, 100LL, Jet A
    56.0 Ocala International-Jim Taylor Field Airport
    (OCF KOCF OCF)    		 251 258 100LL, Jet A-1+
    57.1 Cecil Airport
    (NZC KVQQ VQQ)    		 322 329 100LL, Jet A-1+
    57.1 Gainesville Regional Airport
    (GNV KGNV GNV)    		 283 290 100, Jet A

    Notices to Airmen (NOTAMS)

    NOTAMs

    List ALL KFIN NOTAMs
    View KFIN NOTAMs

    NOTAM Radius Search

    NOTAMS within

    Enter NOTAM radius search distance

    This field is required
    NM of KFIN

    NOTAM Flight Path Search (Enter from two to five locations below)

    NOTAMS within

    Enter NOTAM radius search distance

    This field is required
    NM of KFIN

    Remarks

    A110-10 NOISE ABATEMENT PROCS IN EFCT, VOLUNTARY RESTRAINT FROM TGL OPS 0300-1200Z.
    A110-14 TWY B BTN TWY A1 & D CLSD TO FIXED WING ACFT.
    A110-15 FOR CD OR TO CNL IFR WHEN ATCT IS CLSD CTC DAB APCH AT 386-226-3939.
    A110-16 HEL OPS CONDUCTED WI ARPT BNDRY 500 FT OR BLW UNLESS DRCTD BY ATC; HEL OPS RWY 06 & 29 LEFT TFC; HEL OPS RWY 11 & 24 RIGHT TFC.
    A110-17 NOISE SENSITIVE AREA ALL QUADS OF THE ARPT.
    A16 386-313-4220
    A23-11 RWY 11 DSGND CALM WIND RWY FOR ARRS AND DEPS 0300-1100Z.
    A30-18W/36W SEAPLANE LNDG AREA GORE LAKE 3196 FT BY 1633 FT UNMRKD; 40 FT TREES WATER EDGE ALL QUADRANTS; ALL APCHS HDG 180 DEG OR 360 DEG PAST TREES.
    A30-H1 HELIPAD NA EXC FLAGLER COUNTY EMERG SVCS.
    A30A-24 UNLGTD OBSTNS IN APCH; 1080 FT TREES BFR AER.
    A57-06 APCH SLOPE 23:1 TO RWY EOR.
    A57-11 APRCH SLP 34:1 TO AER.
    A70-FUEL-A FOR JET A FUEL AFTER HRS CALL 386-313-4220 24 HRS IN ADVANCE. FUEL NOT AVBL AT LAKE.
    A81-APT WHEN ATCT CLSD, ACTVT REIL RWY 6, 11, 24, & 29; PAPI RWY 6, 24, 11 & 29; MIRL RWYS 6/24 & 11/29 - CTAF.
    E111 EXISTED PRIOR TO 1959.

    Runways

    Runway Summary

    Runways: 06/24
    11/29
    18W/36W
    H1
    Longest Runway: 11/29 is 5500 ft (1676 m) long
    Runways with an Instrument Approach:

    KFIN Airport Runway Details

    Runway 06/24  5001 ft x 100 ft (1524 m x 30 m)
    Runway Length Source:  3RD PARTY SURVEY as of 08/19/2021
    Surface:  Asphalt - Excellent condition - Saw-cut or plastic grooved
    Runway Pavement Class:  19 /F/B/Y/T
    Runway Edge Lights:  Medium Intensity

    Runway Weight Bearing Capacity (in thousands of pounds)
    Single Wheel Landing Gear:  60.0

    Runway 06

    Runway 24
    Elevation:
    		 29.6 31.0
    Latitude:
    		 29-27-38.6628N 29-28-07.4008N
    Longitude:
    		 081-12-43.9550W 081-11-57.8968W
    Runway True Alignment:
    		 055 235
    Glide Path Angle:
    		 3.0 degrees 3.0 degrees
    Traffic Pattern:
    		 Left Left
    Runway Markings Type:
    		 Nonprecision Instrument Nonprecision Instrument
    Runway Markings Condition:
    		Good Good
    Object at End:
    		 TREES TREES
    Object Height:
    		 84 56
    Distance from End:
    		 3075 1325
    Object Centerline Offset:
    		 315 ft. right of centerline 130 ft. left of centerline
    Visual Glide Slope Indicators:
    		 4-Light PAPI On Left Side Of Runway 4-Light PAPI On Left Side Of Runway
    REIL:
    		 Yes Yes
    Threshold Crossing Height:
    		 41 40

    Runway 11/29  5500 ft x 100 ft (1676 m x 30 m)
    Runway Length Source:  3RD PARTY SURVEY as of 02/26/2021
    Surface:  Asphalt - Excellent condition - Saw-cut or plastic grooved
    Runway Pavement Class:  27 /F/A/X/T
    Runway Edge Lights:  Medium Intensity

    Runway Weight Bearing Capacity (in thousands of pounds)
    Single Wheel Landing Gear:  60.0

    Runway 11

    Runway 29
    Elevation:
    		 30.8 30.9
    Latitude:
    		 29-28-13.1713N 29-27-58.5134N
    Longitude:
    		 081-12-45.8606W 081-11-45.9375W
    Runway True Alignment:
    		 106 286
    Glide Path Angle:
    		 3.0 degrees 3.0 degrees
    Traffic Pattern:
    		 Left Left
    Runway Markings Type:
    		 Nonprecision Instrument Nonprecision Instrument
    Runway Markings Condition:
    		Fair Fair
    Object at End:
    		 TREES TREES
    Object Height:
    		 55 69
    Distance from End:
    		 2155 2324
    Object Centerline Offset:
    		 315 ft. right of centerline 130 ft. left of centerline
    Visual Glide Slope Indicators:
    		 4-Light PAPI On Left Side Of Runway 4-Light PAPI On Left Side Of Runway
    REIL:
    		 Yes Yes
    Threshold Crossing Height:
    		 40 40

    Runway 18W/36W  3001 ft x 500 ft (915 m x 152 m)
    Runway Length Source:  3RD PARTY SURVEY as of 02/26/2021
    Surface:  Asphalt - Excellent condition - No special surface treatment

    Runway 18W

    Runway 36W
    Elevation:
    		 22.0 22.0
    Latitude:
    		 29-27-51.0814N 29-27-21.6252N
    Longitude:
    		 081-13-02.0658W 081-12-57.6756W
    Runway True Alignment:
    		 173 353
    Glide Path Angle:
    		 0.0 degrees 0.0 degrees
    Object Centerline Offset:
    		 315 ft. right of centerline 130 ft. left of centerline

    Helipad H1  36 ft x 36 ft (11 m x 11 m)
    Runway Length Source:  OWNER as of 02/02/2009
    Surface:  Asphalt - Excellent condition - No special surface treatment

    Helipad H1
    Elevation:
    		 31.0
    Latitude:
    		 29-28-22.8600N
    Longitude:
    		 081-12-31.3500W
    Glide Path Angle:
    		 0.0 degrees 0.0 degrees
    Object Centerline Offset:
    		 315 ft. right of centerline 130 ft. left of centerline

    Services

    Airframe Repair:
    		 Major
    Powerplant Repair:
    		 Major
    Bottled Oxygen:
    		 High Pressure
    Bulk Oxygen:
    		 High Pressure
    Fuel Available:
    		 100, Jet A
    Landing Fees:
    		 No
    Parking:
    		 Hangars and tiedowns available

    Maps & Diagrams

    KFIN Sectional

    Flight Planning
    at skyvector.com

    KFIN Diagram

    Flagler Exec Airport (KFIN) Diagram
