Erie International/Tom Ridge Field Airport

US Flag

Location

Latitude:
42-04-59.1000N (42.083083)
Longitude:
080-10-26.2000W (-80.173944)
Elevation:
732.1 feet MSL (223 m MSL)
Magnetic Variation:
9.5 W (as of May 2021 from WMM2020 model)
Time Zone:
UTC -5.0 (Standard Time)
UTC -4.0 (Daylight Savings Time)
From City:
05 N.M. SW of Erie, Pennsylvania
Found On:
Detroit Chart
FAA Region:
AEA

Contacts

Manager:
Publicly owned:
DEREK MARTIN
4411 W 12TH ST
ERIE, PA 16505
814-833-4258
ERIE REGIONAL ARPT AUTHORITY
4411 W 12TH ST
ERIE, PA 16505
814-833-4258

Operations

Airport Status:
Operational
Facility Use:
Public
Type:
Airport
Activation Date:
05/1938
Control tower:
Yes
Attendance (Months/Days/Hours):
Months/Days/Hours
ALL/MON-FRI/0500-2300
Boundary ARTCC:
ZOB (Cleveland)
Responsible ARTCC:
ZOB (Cleveland)
Lighting Schedule:
SEE RMK
Segmented Circle Indicator:
Yes
Beacon Color:
White-Green (Lighted Land Airport)
Traffic Pattern Altitude:
1732 feet (528 m)
NOTAMs Facility:
ERI
NOTAM-D Service:
Yes
International Airport of Entry:
No
Customs Landing Rights:
Yes
Military Landing Rights:
Yes
Civil/Military Joint Use:
No
Aircraft Rescue and Firefighting:
Class I
ARFF Index: B
Air Carrier Service: Scheduled
Certification Date: 05/1973

Based Aircraft

Single Engine:  47
Multi Engine:  1

Annual Operations (as of 12/31/2019)

Total Operations:  27200
Air Taxi:  6565 24.1%
GA Local:  9290 34.2%
GA Itinerant:  11085 40.8%
Military Aircraft:  260 1.0%

Communications

CTAF:  118.100
Unicom:  122.950
Tower:  ERIE
118.1
257.8
Hrs: 0600-0000
Clearance Del.:  126.8
Ground:  121.9
Approach:  BUFFALO
121.0
CLEVELAND ARTCC
Departure:  BUFFALO
121.0
CLEVELAND ARTCC
ATIS:  120.35
Hrs: 24
ASOS:  120.35 (814-835-7112)
EMERG:  121.5
EMERG:  243.0
TRSA:  257.8

  • APCH/DEP SVC PRVDD BY BUFFALO APCH (BUF) ON FREQS 121.0/257.8 0600-0000. APCH/DEP SVC PRVDD BY CLEVELAND ARTCC (ZOB) ON FREQS 127.075/292.175 (WATERFORD RCAG) 0000-0600.
  • ELEV 1099.9 FT.


Fixed Based Operators (FBOs) & Fuel

(Click on a business for detail)
Please help us keep this information up to date. This is a FREE SERVICE just like everything else on Airport Guide! If you see that a business needs to be added, modified, or deleted please fill out our Update Form.

Area Code: 814

Business Name Frequency Phone Fuel Grade
Erie Airways

Unicom 122.95 833-1188 100LL, Mogas, Jet A
To add, modify, or delete a business click here.

Flight Service Stations

Primary Alternate
FSS on Field:  N
FSS Name (ID):  Altoona(AOO)
Frequency:
Toll Free Phone:  1-800-WX-BRIEF

Instrument Procedures / Charts


FAA Terminal Procedures valid from 0901Z 04/22/21 to 0901Z 05/20/21.

There are various types of charts available for an airport. They are listed in the Page Type column. Here is a legend for those types:

APD - Airport Diagram
DP - Departure Procedure Charts
HOT - Hot Spots
IAP - Instrument Approach Procedure Charts
MIN - Minimums
STAR - Standard Terminal Arrival Charts
Page Type Page Name Volume Action Since
Last Cycle
APD AIRPORT DIAGRAM NE-4 Changed
IAP ILS OR LOC RWY 06 NE-4 Changed
IAP ILS OR LOC RWY 24 NE-4 Changed
IAP RNAV (GPS) RWY 06 NE-4 Changed
IAP RNAV (GPS) RWY 24 NE-4 Changed
LAH LAHSO NE-4 Changed
MIN ALTERNATE MINIMUMS NE-4 Changed
MIN TAKEOFF MINIMUMS NE-4 Changed
Terminal Procedures are only available for airports in several countries with more being added all the time. If you are looking for a specific country's charts, please send an email to support(at)airportguide.com stating the country name. This will be used to prioritize the implementation.

Navigation Aids (Navaids) near ERI

Navigational Aid (NAVAID) distances from the airport are listed in Nautical Miles (NM).

Nearby Airports with Fuel

Dist (NM) Name (Airport IDs) True Hdg Mag Hdg Fuel Grade
26.0 Corry-Lawrence Airport
(8G2)
113 123 100LL, Jet A
29.7 Northeast Ohio Regional Airport
(JFN KHZY HZY)
232 241 100LL, Jet A+
37.4 Germack Airport
(7D9)
240 249 100LL
39.4 Greenville Municipal Airport
(4G1)
194 203 100LL
41.0 Chautauqua County/Jamestown Airport
(JHW KJHW JHW)
83 93 100LL, Jet A
44.6 Venango Regional Airport
(FKL KFKL FKL)
161 171 100LL, Jet A
47.0 Chautauqua County/Dunkirk Airport
(DKK KDKK DKK)
58 68 100LL, Jet A, Jet A+
51.6 Scandia Air Park Airport
(6PA4)
99 109 MOGAS
52.1 Concord Airpark Airport
(2G1)
241 250 100LL
54.3 Youngstown-Warren Regional Airport
(YNG KYNG YNG)
204 213 100LL, Jet A
56.2 Grove City Airport
(29D)
179 188 100LL, Jet A
59.4 Lake County Exec Airport
(LNN KLNN LNN)
246 255 100LL, Jet A
60.4 Gates Airport
(7D8)
223 232 100LL
61.1 Clarion County Airport
(KAXQ AXQ)
147 157 100LL, Jet A+
66.5 Cuyahoga County Airport
(CGF KCGF CGF)
242 251 100LL, Jet A, Jet A+
67.0 Hamburg Inc Airport
(4G2)
55 65 100LL, MOGAS
70.5 Bradford Regional Airport
(BFD KBFD BFD)
103 113 100LL, Jet A+
71.0 Youngstown Elser Metro Airport
(4G4)
198 207 100LL, Jet A
71.3 Portage County Airport
(KPOV POV)
223 232 100LL, Jet A
72.3 Woodlawn Beach State Park Heliport
(1NY0)
53 64 Jet A

Notices to Airmen (NOTAMS)

NOTAMs

List ALL KERI NOTAMs

NOTAM Radius Search

NOTAMS within

Enter NOTAM radius search distance

This field is required
NM of KERI

NOTAM Flight Path Search (Enter from two to five locations below)

NOTAMS within

Enter NOTAM radius search distance

This field is required
NM of KERI

Remarks

A110-2 BIRDS ON & INVOF ARPT.
A110-3 EXTENSIVE NON-RADIO & ULTRALGT ACFT OPR 3.5-5 NM SOUTHWEST OF ARPT AT OR BLO 700 FT AGL MAY 1-OCT 31 ANNUALLY SR-SS.
A110-4 FLIGHT NOTIFICATION SERVICE (ADCUS) AVAILABLE; PRIOR RESERVATION REQUIRED; PHONE 814-833-1355.
A110-5 RWY 02/20 CLSD TO SKED ACR OPS MORE THAN 9 PAX SEATS AND NON SKED ACR OPS MORE THAN 30 PAX SEATS EXC TAX.
A110-6 FOR CD CTC BUFFALO APCH AT 716-626-6920, WHEN APCH CLSD CTC CLEVELAND ARTCC AT 440-774-0232.
A110-7 INDEX C AVAIL UPON REQUEST
A49-06 MALSR UNMON.
A49-24 MALSR UNMON.
A57-02 APCH RATIO 23:1 TO DTHR FOR +55 FT TREES 459 FT FM RWY END 29 FT RIGHT.
A57-06 APCH RATIO 30:1 TO DTHR FOR +103 FT TREES 2227 FT FM RWY END 699 FT LEFT.
A57-20 APCH RATIO 19:1 TO DTHR FOR +51 FT TREES 680 FT FM RWY END 77 FT LT.
A58-02 +31 FT RR ANGLES ACROSS RWY CL +32 FT OBST LGTD POLE 106 FT FM AER 17 FT RT.
A58-06 +21 FT OBST LGTD POLE AT 8 FT FROM AER 325 FT R, +15 FT BILLBOARD AT 189 FT FROM AER 327 FT R.
A58-20 +15 FT ROAD AT AER 225 FT R. +9 FT FENCE 65 FT FM RWY END 128 FT R.
A81-APT WHEN ATCT CLSD ACTVT MALSR RY 06/24; PAPI RY 06/24; HIRL RY 06/24; VASI RY 20; MIRL RY 02/20 & TWY LGTS - CTAF.
E80 RAMP USAGE FEE FOR ACFT CLEARING CUSTOMS. FEE BASED ON ACFT WGT, CTC ARPT FOR FEE SKED.

Runways

Runway Summary

Runways: 02/20
06/24
Longest Runway: 06/24 is 8420 ft (2566 m) long
Runways with an Instrument Approach: 06, 24

ERI Heliport Runway Details

Runway 02/20  3508 ft x 150 ft (1069 m x 46 m)
Runway Length Source:  3RD PARTY SURVEY as of 11/09/2015
Surface:  Asphalt - Fair condition -
Runway Pavement Class:
Runway Edge Lights:  Medium Intensity

Runway Weight Bearing Capacity (in thousands of pounds)
Single Wheel Landing Gear:  50.0
Dual Wheel Landing Gear:  60.0
Dual Tandem Wheel Landing Gear:  150.0
Dual Dual Tandem Wheel Landing Gear:

Runway 02

Runway 20

Elevation:
731.4 727.3
Latitude:
42-04-39.4929N 42-05-13.6086N
Longitude:
080-10-48.8574W 080-10-40.6862W
True Magnetic Hdg.:
010 190
ILS Type:
Glide Path Angle:
0.0 degrees 4.0 degrees
Traffic Pattern:
Left Left
Runway Markings Type:
Nonprecision Instrument Nonprecision Instrument
Runway Markings Condition:
Good Good
Arresting Device:
Object at End:
RR ROAD
Object Height:
31 17
Object Marked/Lighted?:
Lighted
Distance from End:
200 200
Object Centerline Offset:
0 ft. left and right of centerline 0 ft. left and right of centerline
Visual Glide Slope Indicators:
4-Box VASI On Left Side Of Runway
Runway Visual Range (RVR):
Approach Light System:
REIL:
Touchdown Lights:
Centerline Lights:
Threshold Crossing Height:
69
Threshold Elevation:
730.1 726.6
Displaced Threshold:
817 306
Threshold Latitude:
42-04-47.4384N 42-05-10.6315N

Threshold Longitude:

080-10-46.9531W 080-10-41.4049W
Declared Distances
Take Off Run Avbl. (TORA):
3508 3508
Take Off Distance Avbl. (TODA):
3508 3508
Actual Stop Dist. Avbl. (ASDA):
3337 3208
Landing Dist. Avbl. (LDA):
2520 2902

Runway 06/24  8420 ft x 150 ft (2566 m x 46 m)
Runway Length Source:  3RD PARTY SURVEY as of 11/09/2015
Surface:  Asphalt - Fair condition - Saw-cut or plastic grooved
Runway Pavement Class:  45 /F/C/X/T
Runway Edge Lights:  High Intensity

Runway Weight Bearing Capacity (in thousands of pounds)
Single Wheel Landing Gear:  114.0
Dual Wheel Landing Gear:  161.0
Dual Tandem Wheel Landing Gear:  264.0
Dual Dual Tandem Wheel Landing Gear:

Runway 06

Runway 24

Elevation:
731.7 723.5
Latitude:
42-04-35.9436N 42-05-24.2584N
Longitude:
080-11-03.8314W 080-09-32.9468W
True Magnetic Hdg.:
054 234
ILS Type:
ILS/DME ILS/DME
Glide Path Angle:
3.0 degrees 3.0 degrees
Traffic Pattern:
Left Left
Runway Markings Type:
Precision Instrument Precision Instrument
Runway Markings Condition:
Good Good
Arresting Device:
Object at End:
RR TREES
Object Height:
31 98
Object Marked/Lighted?:
Lighted
Distance from End:
202 1544
Object Centerline Offset:
0 ft. left and right of centerline 0 ft. left and right of centerline
Visual Glide Slope Indicators:
4-Light PAPI On Left Side Of Runway 4-Light PAPI On Left Side Of Runway
Runway Visual Range (RVR):
Touchdown, Rollout Touchdown, Rollout
Approach Light System:
1,400 Foot Medium Intensity Approach Lighting System With Runway Alignment Indicator Lights 1,400 Foot Medium Intensity Approach Lighting System With Runway Alignment Indicator Lights
REIL:
Touchdown Lights:
Centerline Lights:
Threshold Crossing Height:
54 55
Threshold Elevation:
731.8
Displaced Threshold:
919
Threshold Latitude:
42-04-41.2200N

Threshold Longitude:

080-10-53.9097W
Declared Distances
Take Off Run Avbl. (TORA):
8420 8420
Take Off Distance Avbl. (TODA):
8420 8420
Actual Stop Dist. Avbl. (ASDA):
8420 7501
Landing Dist. Avbl. (LDA):
7501 7501

Services

Fuel Available:
Jet A
Landing Fees:
No

Maps & Diagrams

ERI Heliport Terminal Map

Erie - Woodlawn Beach State Park (ERI) Airport Terminal Map - Overview

To license this image, please contact us.

ERI Heliport Sectional

Flight Planning
at skyvector.com

ERI Heliport Diagram


Do you have a better diagram of this Heliport?
Please share it with us.
