Gruver Municipal Airport

US Flag

FAA: E19


View AFD

View Notices

Location

Latitude:
 36-14-01.4140N (36.233726)
Longitude:
 101-25-55.8820W (-101.432189)
Elevation:
 3205.3 feet MSL (977 m MSL)
Magnetic Variation:
 5.4 E (as of December 2024 from WMM2020 model)
Time Zone:
 UTC -6.0 (Standard Time)
UTC -5.0 (Daylight Savings Time)
From City:
 02 N.M. SW of Gruver, Texas
Found On:
 Wichita Chart
FAA Region:
 ASW

Contacts

Manager:
Publicly owned:
JOHNNIE WILLIAMS
PO BOX 947
GRUVER, TX 79040
806-733-2424		 CITY OF GRUVER
PO BOX 947
GRUVER, TX 79040
806-733-2424

Operations

Airport Status:
 Operational
Facility Use:
 Public
Type:
 Airport
Activation Date:
 12/1978
Control tower:
 No
Attendance (Months/Days/Hours):
 Months/Days/Hours
Unattended
Boundary ARTCC:
 ZAB (Albuquerque)
Responsible ARTCC:
 ZAB (Albuquerque)
Lighting Schedule:
 SEE RMK
Segmented Circle Indicator:
 Yes
Traffic Pattern Altitude (MSL):
 4205 feet (1282 m)
NOTAMs Facility:
 FTW
NOTAM-D Service:
 Yes
International Airport of Entry:
 No
Customs Landing Rights:
 No
Military Landing Rights:
 Yes

Based Aircraft

Annual Operations (as of )

Communications

CTAF:  122.900

  • APCH/DEP SVC PRVDD BY ALBUQUERQUE ARTCC (ZAB) ON FREQS 127.85/285.475 (AMARILLO RCAG).


Fixed Based Operators (FBOs) & Fuel

(Click on a business for detail)
Please help us keep this information up to date. This is a FREE SERVICE just like everything else on Airport Guide! If you see that a business needs to be added, modified, or deleted please fill out our Update Form.

Area Code: 806
Business Name Frequency Phone Fuel Grade
To add, modify, or delete a business click here.

Flight Service Stations

Primary Alternate
FSS on Field:  N
FSS Name (ID):  Fort Worth(FTW)
Frequency:
Toll Free Phone:  1-800-WX-BRIEF

Instrument Procedures / Charts


FAA Terminal Procedures valid from 0901Z 10/03/24 to 0901Z 10/31/24.

There are various types of charts available for an airport. They are listed in the Page Type column. Here is a legend for those types:

APD - Airport Diagram
DP - Departure Procedure Charts
HOT - Hot Spots
IAP - Instrument Approach Procedure Charts
MIN - Minimums
STAR - Standard Terminal Arrival Charts
Page Type Page Name Volume Action Since
Last Cycle
IAP RNAV (GPS) RWY 02 SC-2
IAP RNAV (GPS) RWY 20 SC-2
MIN TAKEOFF MINIMUMS SC-2
Terminal Procedures are only available for airports in several countries with more being added all the time. If you are looking for a specific country's charts, please send an email to support(at)airportguide.com stating the country name. This will be used to prioritize the implementation.

Navigation Aids (Navaids) near E19

Navigational Aid (NAVAID) distances from the airport are listed in Nautical Miles (NM).

Nearby Airports with Fuel

Dist (NM) Name (Airport IDs) True Hdg Mag Hdg Fuel Grade
27.3 Guymon Municipal Airport
(GUY KGUY GUY)		 352 347 100LL, Jet A
32.0 Hutchinson County Airport
(BGD KBGD BGD)		 176 171 100LL, Jet A+
34.6 Perryton Ochiltree County Airport
(KPYX PYX)		 71 66 100LL, Jet A-1+
36.1 Moore County Airport
(KDUX DUX)		 231 225 100LL, Jet A
42.8 Perry Lefors Field Airport
(PPA KPPA PPA)		 150 145 100LL, Jet A-1+
48.4 Miller Airfield Airport
(25TS)		 260 254 100LL, MOGAS
53.7 Liberal Mid-America Regional Airport
(LBL KLBL LBL)		 24 19 100LL, Jet A
53.9 Hemphill County Airport
(KHHF HHF)		 111 106 100LL, Jet A, Jet A++100
55.5 Dalhart Municipal Airport
(DHT KDHT DHT)		 257 251 100LL, Jet A-1
62.3 Rick Husband Amarillo International Airport
(AMA KAMA AMA)		 192 187 100LL, Jet A-1+
69.4 Judy Ranch Airport
(OK39)		 50 45 100LL
73.5 Buffalo Airport
(1E7)		 197 191 100LL, MOGAS
82.3 Ulysses Airport
(KULS ULS)		 1 356 100LL, Jet A
82.4 Stanton County Municipal Airport
(KJHN JHN)		 350 344 100LL, Jet A
84.0 Clayton Municipal Airpark Airport
(CAO KCAO CAO)		 279 273 100LL, Jet A
93.1 West Woodward Airport
(WWR KWWR WWR)		 81 77 100LL, Jet A+
93.2 Hereford Municipal Airport
(KHRX HRX)		 208 202 100LL, Jet A

Notices to Airmen (NOTAMS)

NOTAMs

List ALL E19 NOTAMs
View E19 NOTAMs

NOTAM Radius Search

NOTAMS within

Enter NOTAM radius search distance

This field is required
NM of E19

NOTAM Flight Path Search (Enter from two to five locations below)

NOTAMS within

Enter NOTAM radius search distance

This field is required
NM of E19

Remarks

A110*G THIS AIRPORT HAS BEEN SURVEYED BY THE NATIONAL GEODETIC SURVEY.
A110-1 FOR CD CTC ALBUQUERQUE ARTCC AT 505-856-4861.
A14 CITY MANAGER.
A33-02/20 EXTSV PAVEMENT CRACKING, POTHOLES AT RWY 20 THR.
A42-02 MKGS FADED.
A42-20 MKGS FADED.
A58-02 4 FT FENCE AT THR, 200 FT LEFT.
A81-APT ACTVT MIRL RWY 02/20 - CTAF.

Runways

Runway Summary

Runways: 02/20
Longest Runway: 02/20 is 4698 ft (1432 m) long
Runways with an Instrument Approach:

E19 Airport Runway Details

Runway 02/20  4698 ft x 60 ft (1432 m x 18 m)
Runway Length Source:  NGS as of 03/19/1997
Surface:  Asphalt - Poor condition - No special surface treatment
Runway Edge Lights:  Medium Intensity

Runway Weight Bearing Capacity (in thousands of pounds)
Single Wheel Landing Gear:  12.5

Runway 02

Runway 20
Elevation:
 3205.3 3186.8
Latitude:
 36-13-41.3540N 36-14-21.4220N
Longitude:
 101-26-10.4000W 101-25-41.3860W
Runway True Alignment:
 030 210
Glide Path Angle:
 0.0 degrees 0.0 degrees
Traffic Pattern:
 Left Left
Runway Markings Type:
 Nonprecision Instrument Nonprecision Instrument
Runway Markings Condition:
Poor Poor
Object at End:
 FENCE
Object Height:
 4
Distance from End:
 200
Object Centerline Offset:
 197 ft. left of centerline

Services

Airframe Repair:
 Major
Powerplant Repair:
 Major
Bottled Oxygen:
 None
Bulk Oxygen:
 None
Fuel Available:
 100LL, Jet A
Landing Fees:
 No
Parking:
 Hangars and tiedowns available

Maps & Diagrams

E19 Sectional

Flight Planning
at skyvector.com

E19 Diagram


Do you have a better diagram of this ?
Please share it with us.
