Spokane International Airport

US Flag

Spokane Weather (°F)

KGEG (0.3 NM at True Heading of 58)
METAR: KGEG 101853Z 05009KT 1/8SM R21/0600V1000FT FG SCT001 OVC002 00/00 A2976 RMK AO2 SFC VIS 1/4 SLP093 T00000000
TAF: KGEG 101740Z 1018/1118 06009KT 1/4SM FZFG VV001 FM102000 05005KT 3SM BR OVC004 FM102200 04005KT P6SM SCT008 FM110400 04006KT 1/4SM FG OVC003

Location

Latitude:
47-37-08.5000N (47.619028)
Longitude:
117-32-06.8000W (-117.535222)
Elevation:
2385.0 feet MSL (727 m MSL)
Magnetic Variation:
14.2 E (as of January 2023 from WMM2020 model)
Time Zone:
UTC -8.0 (Standard Time)
UTC -7.0 (Daylight Savings Time)
From City:
05 N.M. SW of Spokane, Washington
Found On:
Seattle Chart
FAA Region:
ANM

Contacts

Manager:
Publicly owned:
LAWRENCE J KRAUTER
9000 W AIRPORT DR., SUITE 204
SPOKANE, WA 99224
(509) 455-6418
SPOKANE COUNTY-CITY
ARPT BOARD, 9000 W AIRPORT DRIVE
SPOKANE, WA 99224
509-455-6455

Operations

Airport Status:
Operational
Facility Use:
Public
Type:
Airport
Activation Date:
08/1943
Control tower:
Yes
Attendance (Months/Days/Hours):
Months/Days/Hours
ALL/ALL/ALL
Boundary ARTCC:
ZSE (Seattle)
Responsible ARTCC:
ZSE (Seattle)
Segmented Circle Indicator:
No
Traffic Pattern Altitude (MSL):
3385 feet (1032 m)
NOTAMs Facility:
GEG
NOTAM-D Service:
Yes
International Airport of Entry:
Yes
Customs Landing Rights:
No
Military Landing Rights:
Yes
Civil/Military Joint Use:
No
Aircraft Rescue and Firefighting:
Class I
ARFF Index: C
Air Carrier Service: Scheduled
Certification Date: 05/1973

Based Aircraft

Single Engine:  36
Multi Engine:  10
Jet Engine:  12
GA Helicopters:  2

Annual Operations (as of 01/01/2019)

Total Operations:  68256
Commercial:  46134 67.6%
Air Taxi:  7423 10.9%
GA Local:  4489 6.6%
GA Itinerant:  7906 11.6%
Military Aircraft:  2304 3.4%

Communications

Unicom:  122.950
Tower:  SPOKANE
118.3
278.3
Hrs: 24
Clearance Del.:  127.55
Ground:  121.9
348.6
Approach:  SPOKANE
123.75 ;205-025
133.35 ;026-204
263.0 ;026-204
282.25 ;205-025
Hrs: 24

372.9
Departure:  SPOKANE
123.75 ;205-025
133.35 ;026-204
263.0 ;026-204
282.25 ;205-025
Hrs: 24

372.9
ATIS:  124.325
254.375
Hrs: 24
ASOS:  (509-742-2544)
EMERG:  243.0
EMERG:  121.5
CLASS C:  263.0 ;026-204
CLASS C:  123.75 ;205-025
CLASS C:  282.25 ;205-025
CLASS C:  133.35 ;026-204



    Fixed Based Operators (FBOs) & Fuel

    (Click on a business for detail)
    Please help us keep this information up to date. This is a FREE SERVICE just like everything else on Airport Guide! If you see that a business needs to be added, modified, or deleted please fill out our Update Form.

    Area Code: 509

    Business Name Frequency Phone Fuel Grade
    Signature Flight Support
       Email
    Unicom: 122.95, Arinc: 122.775 +1 509 455 5204
    Spokane Airways, Inc.

    Unicom 122.95 747-2017 100LL, Jet A
    To add, modify, or delete a business click here.

    Flight Service Stations

    Primary Alternate
    FSS on Field:  N
    FSS Name (ID):  Seattle(SEA)
    Frequency:
    Toll Free Phone:  1-800-WX-BRIEF

    Instrument Procedures / Charts


    FAA Terminal Procedures valid from 0901Z 12/29/22 to 0901Z 01/26/23.

    There are various types of charts available for an airport. They are listed in the Page Type column. Here is a legend for those types:

    APD - Airport Diagram
    DP - Departure Procedure Charts
    HOT - Hot Spots
    IAP - Instrument Approach Procedure Charts
    MIN - Minimums
    STAR - Standard Terminal Arrival Charts
    Page Type Page Name Volume Action Since
    Last Cycle
    APD AIRPORT DIAGRAM NW-1 Changed
    DP SPOKANE SIX NW-1
    DP SPOKANE SIX[DELIMITER] CONT.1 NW-1
    IAP ILS OR LOC RWY 03 NW-1
    IAP ILS OR LOC RWY 21 NW-1
    IAP ILS RWY 03 (CAT II - III) NW-1
    IAP ILS RWY 03 (SA CAT I) NW-1
    IAP ILS RWY 21 (CAT II - III) NW-1
    IAP ILS RWY 21 (SA CAT I) NW-1
    IAP RIDDLE HILL VISUAL RWY 08 NW-1
    IAP RNAV (GPS) Y RWY 03 NW-1
    IAP RNAV (GPS) Y RWY 08 NW-1
    IAP RNAV (GPS) Y RWY 21 NW-1
    IAP RNAV (GPS) Y RWY 26 NW-1
    IAP RNAV (RNP) Z RWY 03 NW-1
    IAP RNAV (RNP) Z RWY 08 NW-1
    IAP RNAV (RNP) Z RWY 21 NW-1
    IAP RNAV (RNP) Z RWY 26 NW-1 Changed
    IAP VOR RWY 03 NW-1
    IAP VOR RWY 21 NW-1
    MIN ALTERNATE MINIMUMS NW-1
    MIN DIVERSE VECTOR AREA NW-1
    MIN TAKEOFF MINIMUMS NW-1
    STAR HILIE TWO NW-1
    STAR ZOOMR ONE NW-1
    Terminal Procedures are only available for airports in several countries with more being added all the time. If you are looking for a specific country's charts, please send an email to support(at)airportguide.com stating the country name. This will be used to prioritize the implementation.

    Navigation Aids (Navaids) near GEG

    Navigational Aid (NAVAID) distances from the airport are listed in Nautical Miles (NM).

    Nearby Airports with Fuel

    Dist (NM) Name (Airport IDs) True Hdg Mag Hdg Fuel Grade
    9.4 Felts Field Airport
    (SFF KSFF SFF)
    65 51 100LL, Jet A-1+
    21.3 Deer Park Airport
    (KDEW DEW)
    11 357 100LL, Jet A
    23.4 Rosalia Municipal Airport
    (72S)
    168 154 100LL
    25.9 Davenport Airport
    (68S)
    274 260 100LL
    30.4 Coeur D'alene/Pappy Boyington Field Airport
    (COE KCOE COE)
    71 57 100, Jet A
    30.5 Brooks Seaplane Base
    (S76)
    83 69 100LL
    30.5 Willard Field Airport
    (73S)
    138 124 100LL
    42.7 Jack A Buell Airport
    (S72)
    113 99 100LL
    45.9 Port Of Whitman Business Air Center Airport
    (S94)
    173 159 100LL
    49.5 Wilbur Airport
    (2S8)
    279 264 100LL, Jet A
    54.6 Shoshone County Airport
    (S83)
    94 80 100LL
    55.4 Pullman/Moscow Regional Airport
    (PUW KPUW PUW)
    161 147 100LL, Jet A
    56.6 Sandpoint Airport
    (KSZT SZT)
    43 29 100LL, Jet A
    57.2 Colville Municipal Airport
    (63S)
    346 332 100LL
    65.0 Grand Coulee Dam Airport
    (3W7)
    286 271 Mogas
    65.5 Ione Municipal Airport
    (S23)
    4 350 100LL
    76.5 Grant County International Airport
    (MWH KMWH MWH)
    251 236 100LL, Jet A, Jet A-1+
    77.6 Lewiston/Nez Perce County Airport
    (LWS KLWS LWS)
    163 149 100, 100LL, Jet A
    80.1 Othello Municipal Airport
    (S70)
    232 218 100LL
    82.5 Ephrata Municipal Airport
    (EPH KEPH EPH)
    257 242 100LL

    Notices to Airmen (NOTAMS)

    NOTAMs

    List ALL KGEG NOTAMs

    NOTAM Radius Search

    NOTAMS within

    Enter NOTAM radius search distance

    This field is required
    NM of KGEG

    NOTAM Flight Path Search (Enter from two to five locations below)

    NOTAMS within

    Enter NOTAM radius search distance

    This field is required
    NM of KGEG

    Remarks

    A110-2 BE ALERT TO TURBULENCE OVER SMOKE STACKS 1 MILE EAST OF ARPT.
    A110-4 WATERFOWL & BIRDS ON & INVOF ARPT.
    A110-6 TWY K UNLGTD ON RAMP SIDE ALONG MAINTENANCE RAMP AND IS UNAVBL BELOW 1200 RVR UNLESS UNDER ESCORT BY 'FOLLOW ME'.
    A110-7 PORTIONS OF TWY K NOT VISIBLE FM ATCT.
    A49-21 ALSF 2 MAY BE OPERATED AS SSALR DURING FAVORABLE WX CONDITIONS.
    E111 ESTABD PRIOR 1959

    Runways

    Runway Summary

    Runways: 03/21
    08/26
    Longest Runway: 03/21 is 11002 ft (3353 m) long
    Runways with an Instrument Approach: 03, 21

    GEG Airport Runway Details

    Runway 03/21  11002 ft x 150 ft (3353 m x 46 m)
    Runway Length Source:  NGS as of 03/01/2012
    Surface:  Asphalt/Concrete - Excellent condition - Saw-cut or plastic grooved
    Runway Pavement Class:  88 /R/B/W/T
    Runway Edge Lights:  High Intensity

    Runway Weight Bearing Capacity (in thousands of pounds)
    Single Wheel Landing Gear:  200.0
    Dual Wheel Landing Gear:  200.0
    Dual Tandem Wheel Landing Gear:  400.0

    Runway 03

    Runway 21

    Elevation:
    2385.0 2322.4
    Latitude:
    47-36-36.2909N 47-37-52.3811N
    Longitude:
    117-33-00.2876W 117-31-05.7573W
    Runway True Alignment:
    045 225
    ILS Type:
    ILS/DME ILS/DME
    Glide Path Angle:
    3.0 degrees 3.0 degrees
    Traffic Pattern:
    Right Left
    Runway Markings Type:
    Precision Instrument Precision Instrument
    Runway Markings Condition:
    Good Good
    Object at End:
    GND
    Object Height:
    9
    Distance from End:
    325
    Object Centerline Offset:
    500 ft. left of centerline
    Visual Glide Slope Indicators:
    4-Light PAPI On Left Side Of Runway 4-Light PAPI On Left Side Of Runway
    Runway Visual Range (RVR):
    Touchdown, Midfield, Rollout Touchdown, Midfield, Rollout
    Approach Light System:
    Standard 2,400 Foot High Intensity Approach Lighting System With Sequenced Flashers, Cat. II or III Config. Standard 2,400 Foot High Intensity Approach Lighting System With Sequenced Flashers, Cat. II or III Config.
    Touchdown Lights:
    Yes Yes
    Centerline Lights:
    Yes Yes
    Threshold Crossing Height:
    69 73
    Declared Distances
    Take Off Run Avbl. (TORA):
    11002 11002
    Take Off Distance Avbl. (TODA):
    11002 11002
    Actual Stop Dist. Avbl. (ASDA):
    11002 11002
    Landing Dist. Avbl. (LDA):
    11002 11002

    Runway 08/26  8199 ft x 150 ft (2499 m x 46 m)
    Runway Length Source:  NGS as of 03/01/2012
    Surface:  Asphalt/Concrete - Excellent condition - Saw-cut or plastic grooved
    Runway Pavement Class:  40 /R/B/X/T
    Runway Edge Lights:  Medium Intensity

    Runway Weight Bearing Capacity (in thousands of pounds)
    Single Wheel Landing Gear:  150.0
    Dual Wheel Landing Gear:  180.0
    Dual Tandem Wheel Landing Gear:  280.0

    Runway 08

    Runway 26

    Elevation:
    2376.2 2371.5
    Latitude:
    47-37-01.0687N 47-37-00.3642N
    Longitude:
    117-33-11.7639W 117-31-12.1045W
    Runway True Alignment:
    090 270
    Glide Path Angle:
    3.0 degrees 3.0 degrees
    Traffic Pattern:
    Right Left
    Runway Markings Type:
    Nonprecision Instrument Nonprecision Instrument
    Runway Markings Condition:
    Good Good
    Object Centerline Offset:
    500 ft. left of centerline
    Visual Glide Slope Indicators:
    4-Light PAPI On Right Side Of Runway 4-Light PAPI On Left Side Of Runway
    REIL:
    Yes Yes
    Threshold Crossing Height:
    45 48
    Declared Distances
    Take Off Run Avbl. (TORA):
    8199 8199
    Take Off Distance Avbl. (TODA):
    8199 8199
    Actual Stop Dist. Avbl. (ASDA):
    8199 8199
    Landing Dist. Avbl. (LDA):
    8199 8199

    Services

    Airframe Repair:
    Minor
    Powerplant Repair:
    Minor
    Bottled Oxygen:
    None
    Fuel Available:
    100LL
    Landing Fees:
    No
    Parking:
    Hangars and tiedowns available

    Maps & Diagrams

    GEG Terminal Map

    Spokane - Ephrata Municipal (GEG) Airport Terminal Map - Overview

    To license this image, please contact us.

    GEG Sectional

    Flight Planning
    at skyvector.com

    GEG Diagram


    Do you have a better diagram of this ?
    Please share it with us.
