Budapest Liszt Ferenc international Airport

HU Flag

IATA: BUD

ICAO: LHBP

Budapest Weather

METAR: LHBP 171230Z 33011KT 9999 SCT044 12/01 Q1002 NOSIG

TAF: TAF LHBP 171115Z 1712/1812 32012KT 9999 BKN035 TEMPO 1712/1802 5000 SHRA SCT030CB BKN040 PROB40 TEMPO 1714/1720 VRB15G25KT 3000 TSRAGS BKN030CB BECMG 1720/1723 32005KT

Reporting Station: LHBP (0.0 NM at True Heading of 69)
Visibility: 6+SM
Flight Category: VFR
Altimeter: 1002
Temperature: 12 C (53.6 F)
Dewpoint: 1 C (33.8 F)

Location

Latitude:
 47-25-47.136N (47.436901)
Longitude:
 019-15-39.9348E (19.2556)
Elevation:
 495 feet MSL (151 m MSL)
Magnetic Variation:
 5.7 E (as of April 2024 from WMM2020 model)
Time Zone:
 UTC +1.0 (Standard Time)
UTC +2.0 (Daylight Savings Time)

Contacts

BUD Airport web site
Manager:
:






Operations

Airport Status:
 Operational
Facility Use:
 Public
Type:
 Airport
Traffic Pattern Altitude (MSL):
 1495 feet (456 m)

Based Aircraft

Annual Operations (as of )

Communications

TWR:  118.1
Delivery:  134.55
Apron Guide South:  122.45
Apron Guide West:  131.55
GND:  121.9
BUDAPEST APP:  129.7
ATIS:  132.375
DIRECTOR:  119.5


Fixed Based Operators (FBOs) & Fuel

(Click on a business for detail)
Please help us keep this information up to date. This is a FREE SERVICE just like everything else on Airport Guide! If you see that a business needs to be added, modified, or deleted please fill out our Update Form.
Business Name Frequency Phone Fuel Grade
To add, modify, or delete a business click here.

Flight Service Stations

Primary Alternate
FSS on Field:
FSS Name (ID):
Frequency:
Toll Free Phone:

Instrument Procedures / Charts

Terminal Procedures are only available for airports in several countries with more being added all the time. If you are looking for a specific country's charts, please send an email to support(at)airportguide.com stating the country name. This will be used to prioritize the implementation.

Navigation Aids (Navaids) near BUD

Navigational Aid (NAVAID) distances from the airport are listed in Nautical Miles (NM).

Nearby Airports with Fuel

Dist (NM) Name (Airport IDs) True Hdg Mag Hdg Fuel Grade
86.8 Subotica Airport
(LYSU)		 167 161 100LL
91.4 Piešťany Airport
(PZY LZPP)		 321 315 Jet A1

Notices to Airmen (NOTAMS)

NOTAMs

List ALL LHBP NOTAMs
View LHBP NOTAMs

NOTAM Radius Search

NOTAMS within

Enter NOTAM radius search distance

This field is required
NM of LHBP

NOTAM Flight Path Search (Enter from two to five locations below)

NOTAMS within

Enter NOTAM radius search distance

This field is required
NM of LHBP

Remarks

No remarks for this landing facility

Runways

Runway Summary

Runways: 13L/31R
13R/31L
Longest Runway: 13L/31R is 12162 ft (3707 m) long
Runways with an Instrument Approach:

BUD Airport Runway Details

Runway 13L/31R  12162 ft x 148 ft (3707 m x 45 m)
Runway Edge Lights:  Yes Intensity

Runway 13L

Runway 31R
Elevation:
 495 417
Latitude:
 47.4454 47.423
Longitude:
 19.2575 19.2939
Runway True Alignment:
 132 312
Glide Path Angle:
 0.0 degrees 0.0 degrees
REIL:
 Yes Yes
Threshold Elevation:
 495 417

Runway 13R/31L  9875 ft x 148 ft (3010 m x 45 m)
Runway Edge Lights:  Yes Intensity

Runway 13R

Runway 31L
Elevation:
 450 450
Latitude:
 47.4487 47.4305
Longitude:
 19.2208 19.2502
Runway True Alignment:
 132 312
Glide Path Angle:
 0.0 degrees 0.0 degrees
REIL:
 Yes Yes
Threshold Elevation:
 450 450

Services

Other Services:
 Full ground, passenger and cargo handling

Maps & Diagrams

BUD Terminal Map

Budapest - Piešťany (BUD) Airport Terminal Map - Overview

To license this image, please contact us.

BUD Sectional

Flight Planning
at skyvector.com

BUD Diagram


Do you have a better diagram of this ?
Please share it with us.
